21.5 Inch Ips Tft Lcd Display 1920x1080 With Lvds Interface 30 Pins MV215FHM-N70

Brand Name : BOE

Model Number : MV215FHM-N70

Certification : ROHS

Place of Origin : CHINA

MOQ : 10pcs

Price : USD55

Payment Terms : T/T

Supply Ability : 5000pcs

Delivery Time : 5-8 work days

Packaging Details : 10pcs/box original package

Outline Dimension : 484.464(H)×284.486(V)×11(D)mm

Active Area : 476.064(H)×267.786(V)mm

Viewing Angle : 89/89/89/89

Luminance : 250cd/㎡

Operating TEMP : 0℃~+50℃

Storage TEMP : -20℃~+60℃

Contact Now

21.5 Inch Ips Tft Lcd Display 1920x1080 With Lvds Interface 30 Pins MV215FHM-N70

General Description:

MV215FHM-N70 each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this module is ad apted for a low reflection and higher color type.

Specifications:

Parameter Specification Unit
Active area 476.064(H) × 267.786(V) mm
Number of pixels 1920(H) × 1080(V) pixels
Pixel pitch 0.24795(H) ×0.24795(V) mm
Pixel arrangement RGB Vertical stripe
Display colors 16.7M colors
Display mode Normally Black
Dimensional outline 484.464(H) x 284.486(V) x11(D) typ.

mm
Weight 1800(Typ.) g
Bezel width (L/R/U/D) 4.2/4.2/4.2/ 12.5 mm
Surface Treatment Haze 25%, 3H
Back-light Horizontal arranged, 1-LED Lighting B ar type

Absolute Maximum Ratings:

Parameter Symbol Min. Max. Unit Remarks
Power Supply Voltage VDD -0.3 5.5 V

Ta = 25℃
Logic Supply Voltage VIN VSS-0.3 VDD+0.3 V
Operating Temperature TOP 0 +50 ℃
Storage Temperature TST -20 +60 ℃
LCM Surface Temperatur e (Operation) Tsurface 0 +65 ℃

Electrical Specifications:

Parameter. Min. Typ. Max. Unit
Power Supply Voltage VDD 4.5 5.0 5.5 V
Power Supply Current IDD - 500 1200 mA
In-Rush Current IRUSH - 2.0 3.0 A
Permissible Input Ripple Voltage VRF - - 300 mV
High Level Differential Input Threshold Voltage VIH

-

-

 + 100 mV
Low Level Differential Input Threshold Voltage VIL - 100

-

-

 mV
Differential input voltage VID 200 - 600 mV
Differential input common mode voltage Vcm 1.0 1.2 1.5

Power Consumption

 PD - 2.5 6 W
PBL - 8.98 9.58 W
Ptotal - 11.48 15.58 W

Interface Connection:

Pin No Symbol Function
1 RXO0- Negative Transmission data of Pixel 0 (ODD)
2 RXO0+ Positive Transmission data of Pixel 0 (ODD)
3 RXO1- Negative Transmission data of Pixel 1 (ODD)
4 RXO1+ Positive Transmission data of Pixel 1 (ODD)
5 RXO2- Negative Transmission data of Pixel 2 (ODD)
6 RXO2+ Positive Transmission data of Pixel 2 (ODD)
7 BIST Bist function
8 RXOC- Negative Transmission Clock (ODD)
9 RXOC+ Positive Transmission Clock (ODD)
10 RXO3- Negative Transmission data of Pixel 3 (ODD)
11 RXO3+ Positive Transmission data of Pixel 3 (ODD)
12 RXE0- Negative Transmission data of Pixel 0 (EVEN)
13 RXE0+ Positive Transmission data of Pixel 0 (EVEN)
14 GND Power Ground
15 RXE1- Negative Transmission data of Pixel 1 (EVEN)
16 RXE1+ Positive Transmission data of Pixel 1 (EVEN)
17 GNG Power Ground
18 RXE2- Negative Transmission data of Pixel 2 (EVEN)
19 RXE2+ Positive Transmission data of Pixel 2 (EVEN)
20 RXEC- Negative Transmission Clock (EVEN)
21 RXEC+ Positive Transmission Clock (EVEN)
22 RXE3- Negative Transmission data of Pixel 3 (EVEN)
23 RXE3+ Positive Transmission data of Pixel 3 (EVEN)
24 GND Power Ground
25 NC *Reserved for LCD manufacturer‘s use (CTL_DVR)
26 NC *Reserved for LCD manufacturer‘s use (CE_DVR)
27 NC No Connection
28 VDD

Power Supply: +5V
29 VDD
30 VDD

Handling Precautions:

1.As the electrostatic discharges may break the LCD module, handle the LCD module with care. Peel a protection sheet off from the LCD panel surface as slowly as possible.

2.As the LCD panel and back - light element are made from fragile glass material, impulse and pressure to the LCD module should be avoided.
